Product description

300-355Watt Polycrystalline Solar Panel
Characteristics	SN-P300	SN-P330	SN-P335	SN-P340	SN-P350	SN-P355
Maximum Power(Pmax)	300Wp	330Wp	335Wp	340Wp	350Wp	335Wp
Optimum Operating Voltage/Vmp	30.0V	36.6V	36.9V	38.2V	38.5V	38.7V
Optimum Operating Current/Imp	8.33A	8.78A	8.84A	8.9A	9.09A	9.17A
Open Circuit Voltage /Voc	43.2V	46.1V	46.5V	46.7V	46.9V	47.0V
Short Circuit Current /Isc	9.13A	9.28A	9.36A	9.45A	9.60A	9.69A
Module Efficiency	15.54%	15.30%	15.60%	15.90%	16.20%	16.50%
Weight	19Kg	19Kg	19Kg	19Kg	19Kg	22Kg
Numbers of cells	72(6*12)	72(6*12)	72(6*12)	72(6*12)	72(6*12)	72(6*12)
Cell dimension(mm)	156*156	156*156	156*156	156*156	156*156	156*156
Dimensions(mm)	165099040
Standard test condition	Irradiance 1000W/m²,Module temperature 25℃, AM=1.5

Mechanical Characteristics
Power Tolerance	±3 %
Maximum Series Fuse Rating	15A
Maximum System Voltage	1000V DC
Operating Module Temperature	-40°C to +80°C
Frame Material	Clear Anodized aluminum Frame
Thickness of glass	3.2mm tempered glass
Frame	Anodized aluminum alloy
Laminating material	EVA
Backsheet material	TPT
Junction box	Ip65

Temperature Characteristics
Norminal Operating Cell Temperature(NOCT)	45±2℃
Temperature Coefficient of Pmax	-0.45%/2℃
Temperature Coefficient of Voc	-0.34%/2℃
Temperature Coefficient of Isc	-0.050%/2℃
