High Efficiency Black Mono celll 500W Solar Panel Digital Glass With CE RoHS Approved

Product Categories

Changsheng Solar Technology Development Ltd

Contact Now

Add to Cart

High Efficiency CE Rosh Certified Digital Mono Crystalline 500 Watt Solar Panel Motorhome, Camper, Shed,

Product description

450-500Watt Monocrystalline Solar Panel
Characteristics	SN-M450	SN-M460	SN-M480	SN-M490	SN-M500
Maximum Power(Pmax)	450Wp	460Wp	480Wp	490Wp	500Wp
Optimum Operating Voltage/Vmp	47.87V	48.01V	48.35V	48.45V	48.63V
Optimum Operating Current/Imp	9.4A	9.59A	9.93A	10.12A	10.28A
Open Circuit Voltage /Voc	58.75V	58.75V	58.89V	58.89V	58.95V
Short Circuit Current /Isc	9.73A	9.78A	10.04A	10.67A	10.87A
Module Efficiency	17.56%	17.95%	18.73%	19.15%	19.51%
Weight	28Kg	28Kg	28Kg	28Kg	28Kg
Numbers of cells	96	96	96	96	96
Cell dimension(mm)	156*156	156*156	156*156	156*156	156*156
Dimensions(mm)	1950131045
Standard test condition	Irradiance 1000W/m²,Module temperature 25℃, AM=1.5

High Efficiency Black Mono celll 500W Solar Panel Digital Glass With CE RoHS Approved

Thank you for seeing this,Our products have been generally satisfied and praised by customers,

We can guarantee that you will be satisfied with our products.You can do business with us at ease

.Don't hesitate,Welcome to contact us !
